GRT400
Table sizes mm 600 | 700 | 800 Max. centric load capacity up to kg 3,000 Hydrostatic bearing     Bearing diameter mm 400 Safe max, tilting Torque up to Nm 5,000 Torque motor drive 1     Nominal Speed bis zu RPM 250 Nominal torque up to Nm 1,000 Max. speed up to RPM 500 Locking system     Tangential Torque up to Nm 5,500 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,001
GRT500
Table sizes mm 700 | 800 | 1,000 Max. centric load capacity up to kg 4,000 Hydrostatic bearing     Bearing diameter mm 500 Safe max, tilting Torque up to Nm 10,000 Torque motor drive 1     Nominal Speed bis zu RPM 200 Nominal torque up to Nm 1,500 Max. speed up to RPM 400 Locking system     Tangential Torque up to Nm 12,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,001
GRT650
Table sizes mm 1,000 | 1,200 | 1,400 Max. centric load capacity up to kg 5,000 Hydrostatic bearing     Bearing diameter mm 650 Safe max, tilting Torque up to Nm 15,000 Torque motor drive 1     Nominal Speed bis zu RPM 175 Nominal torque up to Nm 2,000 Max. speed up to RPM 350 Locking system     Tangential Torque up to Nm 20,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,001
GRT800
Table sizes mm 1,250 | 1,400 | 1,600 Max. centric load capacity up to kg 6,000 Hydrostatic bearing     Bearing diameter mm 800 Safe max, tilting Torque up to Nm 25,000 Torque motor drive 1     Nominal Speed bis zu RPM 150 Nominal torque up to Nm 2,500 Max. speed up to RPM 300 Locking system     Tangential Torque up to Nm 25,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,001
GRT1000
Table sizes mm 1400 | 1600 | 1800 Max. centric load capacity up to kg 8,000 Hydrostatic bearing     Bearing diameter mm 1,000 Safe max, tilting Torque up to Nm 40,000 Torque motor drive 1     Nominal Speed bis zu RPM 125 Nominal torque up to Nm 3,500 Max. speed up to RPM 250 Locking system     Tangential Torque up to Nm 30,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,001
GRT1400
Table sizes mm 1800 | 2000 | 2200 Max. centric load capacity up to kg 10,000 Hydrostatic bearing     Bearing diameter mm 1,400 Safe max, tilting Torque up to Nm 70,000 Torque motor drive 1     Nominal Speed bis zu RPM 100 Nominal torque up to Nm 7,000 Max. speed up to RPM 200 Locking system     Tangential Torque up to Nm 40,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,002
GRT2000
Table sizes mm 2200 | 2600 | 3000 Max. centric load capacity up to kg 15,000 Hydrostatic bearing     Bearing diameter mm 2,000 Safe max, tilting Torque up to Nm 150,000 Torque motor drive 1     Nominal Speed bis zu RPM 75 Nominal torque up to Nm 10,000 Max. speed up to RPM 150 Locking system     Tangential Torque up to Nm 60,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,001 Truth of running mm 0,002
GRT2800
Table sizes mm 3000 | 3500 | 4000 Max. centric load capacity up to kg 25,000 Hydrostatic bearing     Bearing diameter mm 2,800 Safe max, tilting Torque up to Nm 220,000 Torque motor drive 1     Nominal Speed bis zu RPM 50 Nominal torque up to Nm 14,000 Max. speed up to RPM 100 Locking system     Tangential Torque up to Nm 100,000 Accuracy     Dividing accuracy 2 arcsec +/- 2 Lateral runout 3 mm 0,002 Truth of running mm 0,003
