| Table sizes |
mm |
320 | 380 |
| Load capacity, vertical rotation axis |
kg |
600 |
| Load capacity, horizontal rotation axis 1 |
kg |
300 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
200 |
| Safe max, tilting Torque up to |
Nm |
1,500 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
30 |
| Max. torque S6 up to |
Nm |
580 |
| Nominal Speed bis zu |
RPM |
400 |
| Nominal torque up to |
Nm |
120 |
| Max. speed up to |
RPM |
800 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
1,000 |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,01 |
| Truth of running 4 |
mm |
0,01 |
|
|
| Table sizes |
mm |
380 | 460 |
| Load capacity, vertical rotation axis |
kg |
800 |
| Load capacity, horizontal rotation axis 1 |
kg |
400 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
250 |
| Safe max, tilting Torque up to |
Nm |
4,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
20 |
| Max. torque S6 up to |
Nm |
900 |
| Nominal Speed bis zu |
RPM |
200 |
| Nominal torque up to |
Nm |
320 |
| Max. speed up to |
RPM |
400 |
Locking system |
|
|
| Tangential Torque up to |
|
|
Accuracy |
Nm |
1,700 |
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,01 |
| Truth of running 4 |
mm |
0,01 |
|
|
| Table sizes |
mm |
460 | 550 |
| Load capacity, vertical rotation axis |
kg |
1,000 |
| Load capacity, horizontal rotation axis 1 |
kg |
500 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
320 |
| Safe max, tilting Torque up to |
Nm |
6,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
20 |
| Max. torque S6 up to |
Nm |
1,800 |
| Nominal Speed bis zu |
RPM |
100 |
| Nominal torque up to |
Nm |
720 |
| Max. speed up to |
RPM |
200 |
Locking system |
|
|
| Tangential Torque up to |
|
|
Accuracy |
Nm |
2,800 |
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,01 |
| Truth of running 4 |
mm |
0,01 |
|
|
| Table sizes |
mm |
520 | 630 |
| Load capacity, vertical rotation axis |
kg |
3,500 |
| Load capacity, horizontal rotation axis 1 |
kg |
1,750 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
400 |
| Safe max, tilting Torque up to |
Nm |
12,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
15 |
| Max. torque S6 up to |
Nm |
2,700 |
| Nominal Speed bis zu |
RPM |
100 |
| Nominal torque up to |
Nm |
1,300 |
| Max. speed up to |
RPM |
200 |
Locking system |
|
|
| Tangential Torque up to |
|
|
Accuracy |
Nm |
3,500 |
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,01 |
| Truth of running 4 |
mm |
0,01 |
|
|
| Table sizes |
mm |
630 | 800 |
| Load capacity, vertical rotation axis |
kg |
4,500 |
| Load capacity, horizontal rotation axis 1 |
kg |
2,250 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
460 |
| Safe max, tilting Torque up to |
Nm |
18,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
15 |
| Max. torque S6 up to |
Nm |
3,500 |
| Nominal Speed bis zu |
RPM |
75 |
| Nominal torque up to |
Nm |
2,000 |
| Max. speed up to |
RPM |
150 |
Locking system |
|
|
| Tangential Torque up to |
|
|
Accuracy |
Nm |
5,500 |
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,015 |
| Truth of running 4 |
mm |
0,01 |
|
|
|
| Table sizes |
mm |
650 | 800 | 1,000 |
| Load capacity, vertical rotation axis |
kg |
6,000 |
| Load capacity, horizontal rotation axis 1 |
kg |
3,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
540 |
| Safe max, tilting Torque up to |
Nm |
28,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
15 |
| Max. torque S6 up to |
Nm |
4,000 |
| Nominal Speed bis zu |
RPM |
40 |
| Nominal torque up to |
Nm |
3,000 |
| Max. speed up to |
RPM |
75 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
12,000 |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,02 |
| Truth of running 4 |
mm |
0,01 |
|
|
|
| Table sizes |
mm |
1,000 | 1,200 | 1,400 |
| Load capacity, vertical rotation axis |
kg |
10,000 |
| Load capacity, horizontal rotation axis 1 |
kg |
5,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
670 |
| Safe max, tilting Torque up to |
Nm |
40,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
10 |
| Max. torque S6 up to |
Nm |
8,000 |
| Nominal Speed bis zu |
RPM |
40 |
| Nominal torque up to |
Nm |
3,000 |
| Max. speed up to |
RPM |
75 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
20,000 |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,02 |
| Truth of running 4 |
mm |
0,01 |
|
|
|
| Table sizes |
mm |
1,200 | 1,400 | 1,600 |
| Load capacity, vertical rotation axis |
kg |
15,000 |
| Load capacity, horizontal rotation axis 1 |
kg |
7,500 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
760 |
| Safe max, tilting Torque up to |
Nm |
60,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
8 |
| Max. torque S6 up to |
Nm |
10,500 |
| Nominal Speed bis zu |
RPM |
20 |
| Nominal torque up to |
Nm |
6,500 |
| Max. speed up to |
RPM |
40 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
25,000 |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,02 |
| Truth of running 4 |
mm |
0,01 |
|
|
|
| Table sizes |
mm |
1,400 | 1,600 | 1,800 |
| Load capacity, vertical rotation axis |
kg |
25,000 |
| Load capacity, horizontal rotation axis 1 |
kg |
12,500 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
980 |
| Safe max, tilting Torque up to |
Nm |
90,000 |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
7 |
| Max. torque S6 up to |
Nm |
13,500 |
| Nominal Speed bis zu |
RPM |
10 |
| Nominal torque up to |
Nm |
10,000 |
| Max. speed up to |
RPM |
20 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
30,000 |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
0,025 |
| Truth of running 4 |
mm |
0,01 |
|
|
|
| Table sizes |
mm |
1,600 | 2,000 | 2,500 |
| Load capacity, vertical rotation axis |
kg |
35,000 |— |
| Load capacity, horizontal rotation axis 1 |
kg |
17,500 |— |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
1,250 |
| Safe max, tilting Torque up to |
Nm |
120,000 |— |
Drive 2 |
|
|
| Max. speed S6 up to |
RPM |
6 |
| Max. torque S6 up to |
Nm |
15,500 |
| Nominal Speed bis zu |
RPM |
— |
| Nominal torque up to |
Nm |
— |
| Max. speed up to |
RPM |
— |
Locking system |
|
|
| Tangential Torque up to |
Nm |
35,000 |— |
Accuracy |
|
|
| Dividing accuracy 3 |
arcsec |
+/- 2 |— |
| Lateral runout |
mm |
0,03 |— |
| Truth of running 4 |
mm |
0,01 | — |
说明
1、轴承负荷能力；
2、根据应用程序定制
3、根据测量系统；
4、集线器为中心。
|
|
|
|
|
|
| Table sizes |
mm |
320 | 460 |
| Max. centric load capacity up to |
kg |
400 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
200|250 |
| Safe max, tilting Torque up to |
Nm |
—|2,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
15|20 |
| Max. torque S6 up to |
Nm |
800|600 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
5,000|1,900 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,01 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
460 | 500 |
| Max. centric load capacity up to |
kg |
600 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
250|320 |
| Safe max, tilting Torque up to |
Nm |
—|5,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
15|20 |
| Max. torque S6 up to |
Nm |
3,000|2,000 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
6,000|3,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,01 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
520 | 630 |
| Max. centric load capacity up to |
kg |
1,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
320|400 |
| Safe max, tilting Torque up to |
Nm |
|8,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
15|15 |
| Max. torque S6 up to |
Nm |
4,500|2,700 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
8,000|4,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,01 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
630 | 800 |
| Max. centric load capacity up to |
kg |
1,400 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
400|460 |
| Safe max, tilting Torque up to |
Nm |
—|10,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
10|15 |
| Max. torque S6 up to |
Nm |
5,500|3,500 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
10,000|5,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,015 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
800 | 900 | 1,000 |
| Max. centric load capacity up to |
kg |
2,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
460|540 |
| Safe max, tilting Torque up to |
Nm |
—|13,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
10|15 |
| Max. torque S6 up to |
Nm |
6,200|4,000 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
13,000|8,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,02 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
800 | 1,000 | 1,200 |
| Max. centric load capacity up to |
kg |
3,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
540|670 |
| Safe max, tilting Torque up to |
Nm |
—|16,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
5|10 |
| Max. torque S6 up to |
Nm |
12,000|8,000 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
20,000|15,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,02 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
1,200 | 1,400 | 1,600 |
| Max. centric load capacity up to |
kg |
4,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
670|760 |
| Safe max, tilting Torque up to |
Nm |
—|20,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
5|5 |
| Max. torque S6 up to |
Nm |
20,000|10,500 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
30,000|20,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,02 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
| Table sizes |
mm |
1,600 | 1,800 | 2,000 |
| Max. centric load capacity up to |
kg |
8,000 |
Anti-friction mounting |
|
|
| Bearing diameter |
mm |
760|980 |
| Safe max, tilting Torque up to |
Nm |
—|30,000 |
Drive system (gear) 1 |
|
|
| Max. speed S6 up to |
RPM |
5|5 |
| Max. torque S6 up to |
Nm |
30,000|13,500 |
Locking system |
|
|
| Tangential Torque up to |
Nm |
35,000|25,000 |
Accuracy |
|
|
| Dividing accuracy 2 |
arcsec |
+/- 2 |
| Lateral runout |
mm |
—|0,03 |
| Truth of running 3 |
mm |
—|0,01 |
|
|
|
说明
1、根据应用程序定制；
2、根据测量系统；
3、集线器为中心。 |
